JRJ – 1000H at 85°C, Radial Aluminum Electrolytic Capacitor 7mm Height

jb Capacitors manufactures and markets Radial Aluminum Electrolytic Capacitor with Miniaturized Size and wide Temperature. Following are JRJ 2000H at 85°C, Radial Aluminum Electrolytic Capacitor features, specifications and dimensions. We supply high quality Radial Aluminum Electrolytic Capacitor to you.

Email sales@bec.co.uk or call +44 (0) 845 4900 40 for pricing and more information

Description

JRJ – 1000H at 85°C, Radial Aluminum Electrolytic Capacitor 7mm Height Features

  • Load life of 1000 hours at 85°C
  • L:7mm standard products
  • Excellent Ripple Current Capability
  • RoHS Directive Compliant
Items Performance Characteristics
Operating Temperature Range (°C) -40℃~+85℃
Capacitance Tolerance (25°C, 120Hz) ±20%
Leakage Current (μA) ≤0.01CV or 3μA whichever is greater, (at 20℃, after 2 minutes)
C: Nominal Capacitance (μF) V: Rated Voltage (V)
