JFL – Metallized Polypropylene Film Capacitor Features
- Non-inductive, epoxy dip coated, high moisture resistance.
- Dissipation factor is normally low and it is stable against high frequency and change of temperature.
- Remcommended for high-frequency circuits like s-curve compensating circuit.
- High reliability because of its excellent Self-Healing performance.
|Operating Temperature||-40°C~ +85°C|
|Rated Voltage||100V(2A), 250V(2E), 400V(2G), 630V(2J).|
|Capacitance Range||0.01 ~ 10.0μF|
|Capacitance Tolerance||±5%, ±10%, ±20%|
|Insulation Resistance||UR>100V C≤0.33uF IR ≥25000MΩ,C>0.33uF IR ≥7500s
UR<100V C≤0.33uF IR ≥12500MΩ,C>0.33uF IR ≥3750s
|Dissipation Factor||≤0.002 (at 1KHz) (typical 0.001 max)|
