JCK – 1000H at 105°C SMD Aluminum Electrolytic Capacitor Features
- Chip type, operating with wide temperature range -40~+105°C.
- Designed for surface mounting on high density circuit board.
- Emboss carrier tape packing system is available for automatic insertion.
|Operating Temperature||-40°C~ +105°C|
|Voltage Range||4V ~ 100V.DC|
|Capacitance Range||0.1 ~ 10000μF|
|Capacitance Tolerance||±20% at 120Hz, 20°C|
|Leakage Current||Leakage current (Φ4~Φ10) ≤0.01CV or 3μA, whichever is greater.(after 2 minutes application of rated voltage)
Leakage current (Φ12.5~Φ16) ≤0.03CV or 4μA, whichever is greater.(after 1 minutes application of rated voltage)
