Description
JCA – 6000H at 105°C, Long Life Assurance SMD Aluminum Electrolytic Capacitor Features
- Life time 105℃ 6000hrs standard product
- High stability and reliability
- Reflow soldering is available
- Available for high densify surface mounting
- Comply with the RoHS directive.
Operating Temperature | -40°C~ +105°C | |
---|---|---|
Voltage Range | 160V ~ 450V.DC | |
Capacitance Range | 1 ~ 22μF | |
Capacitance Tolerance | ±20% at 120Hz, 20°C | |
Leakage Current | I = 0.04CV (μA) + 100 (μA) after 2 minutes |
